Dynabrade 48360 1/4" Gearless Rear Exhaust Straight-Line Die Grinder

SKU
48360
$391.85
Ships direct from manufacturer?
Dynabrade's .4 hp die grinders are top-quality tools that offer peak efficiency and longer life. They feature an integrated safety-lock throttle lever for operator comfort and minimized wear. The unique pre-filter provides extra defense against contaminants in the air stream, resulting in increased tool life. The governor-controlled motor maintains consistent speed under load, and the tools are color-coded for easy identification. The ergonomic oval-shaped tool housing conforms to the natural shape of the hand for optimum comfort. The lightweight design reduces the weight of each model by 0.5 oz compared to previous versions. The 3-vane rotor allows for a wider range of tool speeds and achieves stall-torque and horsepower performance equal to tools with a 4-vane rotor. The innovative air flow channel exhaust helps maintain a comfortable temperature for the tool housing. The hardened tool cylinder prevents cracking, and the full-length housing core provides consistent weight distribution. The tactile grip ensures a comfortable and non-slip grip, and the gearless design reduces maintenance and downtime. The sound level is measured according to ISO regulation ISO-15744.
WARNING: Proposition 65 Warning for California Residents View Details
More Information
Manufacturer Dynabrade
Condition New
UPC 00616026483606
Includes
  •  1/4" Collet Insert (01485) and 6 mm Collet Insert (01497)
PDFs

48360_instructionmanual.pdf

Application For use on Metal, Fiberglass, Carbon Fiber, Composites, Rapid Material Removal, Deburring, Finishing and Polishing
Horsepower 0.4 HP
Pressure Rating (PSI) 90 PSI
Speed (RPM) 20,000 RPM
Warranty Lifetime
TypeDie Grinder
Maximum Air Flow Rate23 SCFM
Sound Level76 dB(A)
Collet Insert Size1/4" and 6 mm
Collect Style3 Piece
Air Inlet Thread Size1/4"
Air Inlet Thread TypeNPT
Exhaust TypeRear
Hose Inner Diameter1/4"
Vacuum TypeNon-Vacuum
Tool StyleStraight Line
Motor TypeRotary Vane
Muffler TypeStandard
EAC CertifiedYes
CE CertifiedYes
Length6.4"
Height1.7"
Width6.5"
Weight0.9 lbs
