Compact with high functionality for universal use on the construction site and in the workshop.
Simple and error-proof control concept in the operator's field of view.
Double drill motor guides enable use of the longest annular cutters.
Reversible
Electronic speed control.
High-power motor with stable speed.
High magnetic holding force.
Easy to read convenient magnetic holding force display.
Integrated coolant tank.
Hand feed wheel can be mounted on either side.
MT3 interface.
Magnet monitor system
Memory function
Forward/reverse operation
Includes
Coolant Tank
Safety Strap
Chip Hook
Pilot Pin 4 1/8" (105 mm)
Chip Guard
Drift
Case
Video
Type
Drilling Unit
Power Consumption
1,200 W
Power Output
610 W
Load Speed: 1st Gear (RPM)
130 - 260 (RPM)
Load Speed: 2nd Gear (RPM)
260 - 520 (RPM)
Tool Mount
MT 3
Carbide Cutter Maximum Diameter
2"
Hss Cutter Maximum Diameter
1 5/8"
Cutter Maximum Drilling Depth
2"
Twist Drill Maximum Diameter
7/8"
Tapping
M 16
Maximum Countersinking Diameter
2"
Reaming Maximum Diameter
7/8"
Cutter Holder
3/4" Weldon
Cutter Change
Tool-Free
Stroke
5 11/16"
Total Stroke Range
12 3/8"
Magnetic Holding Force
2810 lbs
Magnetic Base Dimensions
7 11/16" x 3 9/16"
Cable with Plug
13.1 ft
Weight
31.31 lbs
Sound Pressure Level LpA
82,1 dB
Measurement Uncertainty Of The Measured Value KpA
5 dB
Sound Power Level LWA
93,1 dB
Measurement Uncertainty of the Measured Value KWA
5 dB
Peak Sound Value LpCpeak
96,2 dB
Measurement Uncertainty of the Measured Value KpCpeak
5 dB
Aplication
Mag Base Drilling Metal Up to 1 3/8" Diameter, Mag Base Drilling Metal Up to 2" Diameter, Twist Drills with Drill Chuck, Spiral Drilling with Mt Fitting, Tapping, Countersinking, Reaming, Performing Overhead Work, Installation Work, Workshop Jobs
