Our Spektra bits feature a nACo nanocomposite coating with an extreme nanohardness and heat resistance. With a brilliant distinctively-tinted coloring nACo provides additional improvements in four critical aspects of router tooling.
WARNING: Proposition 65 Warning for California Residents View Details
nACo coating is a micro-thin ceramic coating which enables the tool's cutting edge to retain crucial sharpness and lubricity. This provides longevity and produces cutting results of the highest quality
Coating prevents high heat and oxidation which is detrimental to cutting tool performance
Multi-colored hues, while attractive, will dissipate upon use and yet coating will remain fully effective
nACo offers approximately 4,500 Vickers for impressive solid hardness on cutting areas of the tool, for an increase up to 2.5 times compared to uncoated bits
'Up-Cut' spiral. Three-flute design for very high quality finish
Note: Blue based color dissipates immediately upon use. nACo® nanocomposite coating will not wear off
Benefits of Mirror-Finish:
Razor sharp cutting edge
Effortless chip removal
Helps prevent chip re-welding
Extends tool life
Exceptional cut quality
Dissipates heat well and prevents melting
Application
For Creating Grooves and Dado Cuts in Softwood, Hardwood, Plywood and Composite Materials
Flutes
3
Material
Carbide Tip
Type
Router Bit
Direction
Up-Cut
Diameter (D)
1/2"
Cutting Height (B)
1 1/2"
Shank Diameter (d)
1/2"
Overall Length (L)
3 1/2"
Coating
Spektra Extreme Tool Life
Flute Type
Spiral Plunge
Recommended Speed (RPM)
20,000 - 21,000 RPM
Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (Wood/Plywood)
300" / .0057" / 100"
Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (MDF/Laminate)
