These tools have a much shorter up-cut section than the standard compression tools. Spektra bits feature a nACo nanocomposite coating with an extreme nanohardness and heat resistance. With a brilliant distinctively-tinted coloring nACo provides additional improvements in four critical aspects of router tooling.
Note: Blue based color dissipates immediately upon use. nACo nanocomposite coating will not wear off.
WARNING: Proposition 65 Warning for California Residents View Details
nACo coating is a micro-thin ceramic coating which enables the tool's cutting edge to retain crucial sharpness and lubricity. This provides longevity and produces cutting results of the highest quality
Coating prevents high heat and oxidation which is detrimental to cutting tool performance
Multi-colored hues, while attractive, will dissipate upon use and yet coating will remain fully effective
nACo offers approximately 4,500 Vickers for impressive solid hardness on cutting areas of the tool, for an increase up to 2.5 times compared to uncoated bits
Application
For Mortising Grooving and Dado, MDF/HDF, Laminate, Laminated Plywood, Melamine, Particle Board, Softwood/Hardwood, Veneered Plywood
Type
Router Bit
Flutes
2
Material
Solid Carbide
Diameter (D)
1/4"
Cutting Height (B)
7/8"
Cutting Height (B1)
3/16"
Shank (d)
1/4"
Overall Length (L)
3"
Style
Mortise Compression Spiral
Coating
Nanocomposite (nACo)
Feed Rate IPM / Chip Load Per Tooth / Ramp Down (Wood)
110" / .0031" / 55"
Feed Rate IPM / Chip Load Per Tooth / Ramp Down (MDF/Laminate)
220" / .0061"/ 110"
Feed Rate IPM / Chip Load Per Tooth / Ramp Down (Plywood)
110" / .0031"/ 55"
Feed Rate IPM / Chip Load Per Tooth / Ramp Down (Plastic)
