Spiral-flute bits combine a shearing action in cutting with an augering action in chip clearance. The shearing action yields an especially clean accurate cut while the augering action clears chips from the cut. The ‘Down-Cut’ cuts from the surface down leaving a smooth edge at the surface. Special unique carbide grade increased clearance geometry and razor-sharp cutting edges with polished flutes provide a superior finish and longer tool life especially in abrasive materials. Primarily used on CNC machines and other automatic routers. Our Spektra bits feature a nACo nanocomposite coating with an extreme nanohardness and heat resistance. With a brilliant distinctively-tinted coloring nACo provides additional improvements in four critical aspects of router tooling.
Note: Blue based color dissipates immediately upon use. nACo nanocomposite coating will not wear off.
WARNING: Proposition 65 Warning for California Residents View Details
nACo coating is a micro-thin ceramic coating which enables the tool's cutting edge to retain crucial sharpness and lubricity. This provides longevity and produces cutting results of the highest quality
Coating prevents high heat and oxidation which is detrimental to cutting tool performance
Multi-colored hues, while attractive, will dissipate upon use and yet coating will remain fully effective
nACo offers approximately 4,500 Vickers for impressive solid hardness on cutting areas of the tool, for an increase up to 2.5 times compared to uncoated bits
Flutes
2
Material
Solid Carbide
Package Size
5
Type
Router Bit
Diameter (D)
1/8"
Cutting Height (B)
13/16"
Shank Diameter (d)
1/4"
Overall Length (L)
2 1/2"
Style
Spiral Plunge
Direction
Down Cut
Coating
nACo Ceramic
Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (Wood/Plywood)
145" / .0040" / 72.5"
Feed Rate IPM* / Chip Load Per Tooth / Ramp Down (MDF/Laminate)
180" / .0050" / 90"
Suitable for Use with
Handheld and Table-Mounted Portable Routers
Application
For Creating Grooves and Dado Cuts in Particleboard, Plywood and Laminate, and for Cutting Laminate, Melamine, Melamine Particle Board, MDF, Veneered Plywood, Wood
