Creates a harder and tougher cutting edge allows for a prolonged cutting edge life and helps to prevent the build-up of material in the flutes while cutting
Have the tendency to run/spin much faster than an uncoated tool
Optimized flute geometry and low Total Indicated Runout (TIR) guarantees clean cuts, essentially eliminates sanding and reduces chatter (where the machine or work piece vibrates) under high chip loads (when used with low TIR spindles)
High flute volume supports high feed rates and chip loads
High aspect ratio for single pass deep-reach cutting
Flute geometry optimized for cutting sign foam, sign board, hardwoods, thermoplastics and phenolic composites
Flutes
2
Material
Solid Carbide
Type
Router Bit
Direction
Up-Cut
Diameter (D)
1/4"
Radius (R)
1/16"
Cutting Height (B)
3/4"
Shank Diameter (d)
1/4"
Overall Length (L)
2 1/2"
Style
Spiral Plunge with Corner Radius
Application
For Carving, Lettering, Decorative Doors and Sign Manufacturing, and for Cutting Aluminum, MDF, Soft/Hard Plastic, Soft/Hard Wood
