Variable-speed rolling—4 speeds on top roll, 2 speeds on bottom roll rotation—facilitates smooth transition between bend parts
Top roll can switch between progressive (moving profile) and direct (profile stopped) bending
Hydraulically adjustable top roll moves to fit your application’s profile
75 different profile calibrations let you bend multiple radii on a single section
Overload-protected inverter drive lets you shift machine speed from 0 to 8 rpm, cutting down on machine wear and tear
Touchscreen operator podium with attached foot pedal allows for easy programming
Internal memory holds 40 programs of 24 segments per program, cutting down delays on repeat parts
Heavy electro-welded steel construction minimizes flex and helps the R-CNC120 to bend at full capacity for years
Baileigh backs this CNC tube bender with a 1-year parts warranty and lifetime technical support by phone
Double-pinch side-to-side adjustment on bottom rolls reduces the wasteful length of straight material at the ends of each bend that you get on a standard ring roller
Structural-grade steel plate frame supporting the sharp accuracy of CNC production
You’ll find our integrated software easy to operate and program, unlike the complicated setups on many CNC roll benders
Handheld calibration device and cutting-edge CNC technology can automatically produce the desired bend radius without manual adjustment
Motor Phase
3 Ph
Stationary type
Roll Bender
Suitable for Use With
Structural Applications, Playgrounds, Shipyard Building, or Any High-Production, Low-Waste Project
