Spiral-flute bits combine a shearing action in cutting with an augering action in chip clearance. The shearing action yields an especially clean accurate cut while the augering action clears chips from the cut.
The ‘Up-Cut’ shears from the bottom up pulling chips from the bottom up thus allowing deeper penetration with less stress on the tool. An excellent choice for mortising.
Amana Tool solid carbide router bits provide consistent, repeatable quality. Every tool is guaranteed to match the geometry on the prints, every time on every order. Best control of carbide grades for woodworking, and absolute control of quality standards on all carbide blanks. Special unique carbide grade increased clearance geometry and razor-sharp cutting edges with polished flutes provide a superior finish and longer tool life especially in abrasive materials. Great for production settings and excellent for creating grooves and dado cuts in particleboard, plywood and laminate. Primarily used on CNC machines and other automatic routers. Can be used with handheld and table-mounted portable routers.
The Only Spektra Coated Bits.
Our Spektra bits feature a nACo nanocomposite coating with an extreme nanohardness and heat resistance. With a brilliant distinctively-tinted coloring nACo provides additional improvements in four critical aspects of router tooling.
Note: Blue based color dissipates immediately upon use. nACo nanocomposite coating will not wear off.
| Manufacturer | Amana Tool Corp. |
|---|---|
| Condition | New |
| UPC | 00073868548332 |
| Features |
|
| Application | Cork, Laminate, Melamine, Melamine Particle Board, MDF, Veneered Plywood, Wood |
| Diameter(D) | 1/4" |
| Flutes | 2 |
| Material | Solid Carbide |
| Overall Length(L) | 4" |
| Shank(d) | 1/4" |
| Type | Router Bit |
|---|---|
| Helix Direction | Up-Cut |
| Cutting Height (B) | 2" |
| Style | Spiral |
