Pferd 42003015, Combiclick 48705 4-1/2″ 48705 Flap Disc, 5/Box

SKU
42003015
$128.93
Ships direct from manufacturer?

The Combiclick system consists of a specially developed backing pad and a rugged mounting system at the back of the disc. The backing pad allows Combiclick discs to be used on most available angle grinders. The special geometry of the cooling slots ensures high air throughput, which considerably reduces the thermal load on the abrasive material and the workpiece. The quick-mounting system, rugged fixture, secure attachment of the disc and optimized cooling system help to provide up to 30% lower workpiece temperature, up to 25% increased stock removal, up to 30% longer disc life and improved utilization of the abrasive.

Designed for polishing with polishing paste bars, grinding pastes or diamond polishing pastes in face-down grinding on medium-sized and large surfaces.

Recommendations for Use

Use Combiclick felt discs with Combiclick backing pads on variable speed angle grinders.

For the best performance, use with a recommended peripheral speed of 1,000-2,000 SFPM. This provides an ideal compromise between polishing performance, thermal load on the workpiece and tool wear.

When applying a different polishing paste, use a new unused felt disc.

Safety Notes

For safety reasons, the maximum permitted rotational speed indicated must never be exceeded.

Ordering Notes

Please order Combiclick backing pads separately.

Please order grinding and polishing pastes separately.

WARNING: Proposition 65 Warning for California Residents View Details
More Information
ManufacturerPferd
ConditionNew
UPC097758487054
Features
  • Innovative quick-mounting system guarantees convenient handling and cool grinding
  • Extremely quick and easy disc changes reduce process costs
  • With Combiclick, scratches caused by protruding clamping parts are prevented and very high utilization of the available abrasive is attained
  • Durability makes this cost-effective
  • Precise handling throughout product lifespan due to high dimensional stability
ApplicationPolishing
Package Size5
TypeFlap Disc
Diameter External4-1/2"
EDP No.48705
Maximum RPM10,500 RPM
RPM Optimum1650 RPM
Compatible Power ToolsAngle Grinder, Cordless Angle Grinder, Drive Spindle
Workpiece MaterialsAluminum, Brass, Bronze, Cast Steel, Cobalt-based Alloys, Copper, Fibre-reinforced Thermosetting Plastics (GRP, CRP), Hardened, Heat-treated Steels Over 370 HV (38 HRC), Nickel-based Alloys (E.g. Inconell and Hastelloy), Stainless Steel (INOX), Steel Materials With a Hardness > 54 HRC, Steels Up to 370 HV (< 38 HRC), Thermoplastics, Titanium, Titanium Alloys, Zinc
