Jet 262050 5-HDT 14-13/16" 5 Ton Steel Manual Trolley Ships direct from manufacturer
Jet HDT series manual trolleys are available in capacities from 1/2 ton to 5 tons. They are designed for low maintenance, trouble free use on wide flange H-beams, standard I-beams or curved track. Each Jet manual trolley conforms to OSHA regulations, and ANSI / ASME standards.
WARNING: Proposition 65 Warning for California Residents
View Details More Information Manufacturer Jet Condition New UPC 66275552467 Features
Built-in bumper guards on the side plates increase safety and extend trolley life
Complies with OSHA regulations, ANSI / ASME B30.11 and B30.17 standards
Easily adjustable to wide-flange H-beams, standard I-beams, or curved track with the included spacer washers
Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
Welded all-steel frame and powder coat finish provide maximum durability and protection
Includes
Type Manual Trolley Material Steel Load Capacity 5 Ton (11000 lbs) Hook Mount (Headroom) 7 11/16" Maximum Beam Flange Width 8" Minimum Beam Curve Radius 55" Minimum Beam Flange Width 4 5/8" - 8" Wheel Diameter 4 3/4" Maximum Hook Size 2 1/8" Minimum Beam Height 10" Overall Length 14 13/16" Overall Width 14 13/16" Overall Height 8 9/16" Weight 87 lbs
