Amana Tool 47511 2" Carbide Tipped Cope Cutter with Stub Spindle

SKU
47511
$95.70
Ships direct from manufacturer ?

Our newest design allows us to make beautiful doors with tenons of any length we choose. This unique door-making system utilizes a “stub” spindle & cope cutter arrangement. The counterbored cope cutter is secured to the spindle with a cap screw. A matching profile bit is used to shape the decorative ogee “sticking” along the edges of the stiles and rails. As the cope is cut on the ends of the rails, the tenon passes over the top of the bit unobstructed.

WARNING: Proposition 65 Warning for California Residents View Details
More Information
ManufacturerAmana Tool Corp.
ConditionNew
UPC73868547511
ApplicationFor Making 1-3/4" Thick Entry Doors with an Ogee Sticking
Flutes2
MaterialCarbide Tip
Type Cope Cutter with Stub Spindle
Diameter (D) 2"
Inner Diameter (D1) 3/4"
Radius (R) 11/32"
Cutting Height (B) 11/16"
Shank Diameter (d) 1/2"
Overall Length (L) 2"
Material Size 1 3/4"
