725 [221] ft[m] cutting capacity (in 22 [0.8] gauge [mm] sheet metal) with one battery charge (4 Ah)
Outstanding ergonomics and compact design for optimal mobility of the shear
Indexible cutting blades with four sides for clean and burr-free cutting with low operating costs
Good curve precision with low sheet-metal distortion
Perfect for trimming and cutting
Unrestricted view of the cutting line
Proven MultiMaster motor with outstanding power and durability
Compatible with AMPShare/Bosch Professional 18 V batteries from 2008 on.
Maximum cutting speed with AMPShare 18V batteries: coolpack 2.0 technology ensures a longer battery service life in comparison to batteries without coolpack technology. It makes longer operation times possible. ECP protects batteries against overloading, overheating and deep discharge
Perfectly equipped for any job. Easily transported with our L-BOXX system
Includes
Pair of Blades (31308072000), Mounted
Allen Key 2 mm
Allen Key 3 mm
Hand Guard
Tool Case (L-Boxx 136)
Application
Curve Cuts, Coil Cuts, Inside Cutouts, Notches
Type
Sheet Metal Shear
Battery Voltage
18 V
Battery Compatibility
Li-ion/Core 18 V Li-ions
Battery Interface
18 V AMPShare
Strokes
2,200 - 3,500 SPM
Corded or Cordless
Cordless
Cutting Speed
20 - 30 ft/min
Steel 58,000 lbf/in²
1/16"
Steel 87,000 lbf/in²
3/64"
Steel 116,000 lbf/in²
3/64"
Non-ferrous Metals Up to 36,000 lbf/in²
3/32"
Radius of Smallest Curve
1/2"
Weight without Battery
3.17 lbs
Sound Pressure Level LpA
74.2 dB
Measurement Uncertainty of the Measured Value KpA
3 dB
Sound Power Level LWA
85.2 dB
Measurement Uncertainty of the Measured Value KWA
3 dB
Peak Sound Value LpCpeak
86.0 dB
Measurement Uncertainty of the Measured Value KpCpeak
