| Model Option:10" Jobsite Saw PRO: 1.5HP (4.0HP MAX), 120VAC, 60Hz. Inc. jobsite mobile cart & high/low fence system |
Motor Configuration: 120 VAC 60 Hz, Universal |
Amperage: 15A |
Motor Peak HP: 4 HP |
| Motor Continuous HP: 1.5 HP |
No Load RPM: 4,000 |
Restart Protection: Yes |
Cord Length: 116" |
| Saw Dimensions without Cart: 31-3/4" W x 28-3/4" D x 15-1/2" H |
Saw Dimensions with Open Cart: 48" W x 29" D x 36" H |
Saw Dimensions with Closed Cart (on End): 26-1/2" W x 29" D x 45" H |
Table Dimensions (Retracted): 31-1/4" W x 24-5/8" D |
| Table Dimensions (Extended): 43-3/8" W x 24-5/8" D |
Shipping Dimensions: 32" W x 43" D x 26" H |
Weight (Saw Only): 84 lbs |
Weight (with Cart): 113 lbs |
| Shipping Weight (with Cart): 137 lbs |
Blade Diameter: 10" |
Dado Diameter: 8" |
Dado Max. Width: 13/16" |
| Bevel Angle Range: -1 to 46 |
Blade Tilt: Left |
Max. Depth of Cut, Blade at 0º: 3-1/8" |
Max. Depth of Cut, Blade at 45º: 2-1/8" |
| Max. Rip Right of Blade (Extended): 25-1/2" |
Max. Rip Left of Blade: 9-3/4" |
Arbor Diameter at Blade: 5/8" |
Main Bearing Size: 62mm OD x 30mm ID x 16mm W |
| Second Bearing Size: 52mm OD x 25mm ID x 15mm W |
Table in Front of Blade (Max Elev): 7-7/8" |
Table Behind Blade (Max Elev): 7-3/8" |
Miter Slots T-shaped Dimensions: .754" W x .413" D; "T" .956" W x .157" THK |
| Dust Collection Port Diameter: 2-9/16" Outside, 2-1/4" Inside |
Riving Knife/Splitter Thickness: 2.3mm (.090") |
Active Dust Collection Blade Guard: polycarbonate, extends 1" right of blade |
Blade Guard (Dust Collection) Port Diameter: 1-11/16" Outside, 1-3/8" Inside |
| Hand Wheel: Effective diameter 6.3" |
Belts: Poly-V static dissipative belt |
Table Flatness Measured Diagonally: 0.033" Inches |
|
